Alpha WireUnited States
3210
ActiveAlpha Wire 24 AWG, 1 Conductor Communication Cable provides precise signal transmission for computer and control applications
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| 1) Voltage Rating | 600 V RMS |
| Environment and package | |
| 1) Temperature Range | -55 to 105°C |
| Other | |
| 1 | WHITE |
| (1) Color Code | Alpha Wire Color Code G |
| 1) Component 1 | 1 x 1 COND |
| 1) Military | a) Component 1 |
| 2) Bend Radius | 10X Cable Diameter |
| 2) CE | EU Low Voltage Directive 2014/35/EU |
| 2) Ground Capacitance | 101 pF/ft @1 kHz, Nominal |
| 2) Shield | Tinned Copper BRAID Shield,90% Coverage, Min. |
| 3) California Proposition 65 | This product may contain substances known to the State of California to cause Cancer or Reproductive Harm, but is exempt from labeling based on the Consent Judgement. See the Alpha Wire website for more detail. |
| 3) Inductance | 0.043 μH/ft, Nominal |
| 3) Pull Tension | 1.98 bs. (max.) |
| 4) OA Shield DCR | 10.6 Ω/1000ft @20°C, Nominal |
| a) 1000 FT | 6.5 x 6 x 1.9 Continuous Length |
| a) Color(s) | SLATE |
| b) 500 FT | 6.5 x 4 x 2.5 Continuous Length |
| b) Print | ALPHA WIRE-* P/N 3210 CE ROHS * = Factory Code |
| c) 100 FT | 3.5 x 3 x 1.125 Continuous Length |
| Color | WHITE |
| Cond | 1 |
| Electrical Properties | For Engineering purposes only |
| Packaging | Flange x Traverse x Barrel (inches) |
