Preci-DipSwitzerland
CONN SOCKET 5POS 0.07 GOLD PCB
All alternatives
View full reportTechnical parameters
Key specs
Positions5
Rows1
Pitch1.78 mm
GenderFemale
Current rating1 AMax
| Power | |
|---|---|
| Current Rating (Amps) | 1A |
| Voltage Rating | - |
| Environment and package | |
| Insulation Height | 0.165" (4.20mm) |
| Mated Stacking Heights | - |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C~125°C |
| Package | Bulk |
| Other | |
| Applications | - |
| Base Product Number | 317-83 |
| Connector Type | Socket |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Tin |
| Contact Finish Thickness - Mating | 29.5µin (0.75µm) |
| Contact Finish Thickness - Post | - |
| Contact Length - Post | 0.125" (3.18mm) |
| Contact Material | Beryllium Copper |
| Contact Shape | Circular |
| Contact Type | Female Socket |
| Fastening Type | Push-Pull |
| Features | - |
| Ingress Protection | - |
| Insulation Color | Black |
| Insulation Material | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled |
| Material Flammability Rating | UL94 V-0 |
| Mfr | Preci-Dip |
| Number of Positions | 5 |
| Number of Positions Loaded | All |
| Number of Rows | 1 |
| Pitch - Mating | 0.070" (1.78mm) |
| Product Status | Active |
| Row Spacing - Mating | - |
| Series | 317 |
| Style | Board to Board |
| Termination | Solder |
