315
Adafruit Industries LLCUnited States

315

ObsoleteLED Indication - Discrete4-DIP

LED RGB DIFF 5MM RND T/H 1=25PC

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

ColorMulticolor
Wavelength630 nm
Forward voltage3.8 VMax
Test current20 mA
Luminous intensity400 mcd ~ 1.2 cd
Power
Current - Test20mA Red, 20mA Green, 20mA Blue
Voltage - Forward (Vf) (Typ)2.1V Red, 3.8V Green, 2.7V Blue
Environment and package
Height (Max)10.10mm
Lens Size5.00mm
Mounting TypeThrough Hole
PackageBulk
Package / Case4-DIP (0.200", 5.08mm)
Size / Dimension7.62mm L x 7.62mm W
Supplier Device Package5mm Round
Other
ColorRed, Green, Blue (RGB)
ConfigurationCommon Anode
Features-
Lens ColorWhite
Lens StyleSquare with Domed Top
Lens TransparencyDiffused
MfrAdafruit Industries LLC
Millicandela Rating400mcd Red, 1200mcd Green, 400mcd Blue
Product StatusObsolete
Series-
Viewing Angle80°
Wavelength - Dominant-
Wavelength - Peak630nm Red, 525nm Green, 470nm Blue
