View full reportTechnical parameters
Key specs
Rated current2 A
Rated voltage1 kV
| Power | |
|---|---|
| Breaking Capacity @ Rated Voltage | - |
| Current Rating (Amps) | 2 A |
| Voltage Rating - DC | 1000 V |
| Environment and package | |
| Mounting Type | Requires Holder |
| Operating Temperature | - |
| Package | Bulk |
| Package / Case | 5AG, 10mm x 38mm (Midget) |
| Size / Dimension | 0.406" Dia x 1.496" L (10.30mm x 38.00mm) |
| Other | |
| Approval Agency | UL |
| Color | - |
| Fuse Type | Cartridge, Ceramic |
| Mfr | Phoenix Contact |
| Product Status | Active |
| Response Time | - |
| Series | - |
