View full reportTechnical parameters
| Power | |
|---|---|
| Current - IEC | 30 A |
| Current - UL | 30 A |
| Voltage - IEC | 1000V |
| Voltage - UL | 600V |
| Other | |
| Color | Blue |
| Disconnect Type | Switch, Lever |
| Features | - |
| Fuse Type | - |
| Manufacturer | Phoenix Contact |
| Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polyamide (PA), Nylon |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Packaging | Bulk |
| Part Status | Last Time Buy |
| Series | CLIPLINE ST |
| Stripping Length | 12mm |
| Terminal - Width | 8.2mm |
| Termination Style | Push In, Spring |
| Type | Disconnect |
| Wire Gauge or Range - AWG | 8-24 AWG |
| Wire Gauge or Range - mm² | 0.2-10mm² |
