LEDdynamics Inc.United States
LED SUPP CC AC/DC 32V 350MA 7SIP
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output (Max) | 350mA |
| Power (Watts) | 11 W |
| Voltage - Input (Max) | 24VAC |
| Voltage - Input (Min) | 7VAC |
| Voltage - Output | 32V (Max) |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~80°C |
| Package | Bulk |
| Package / Case | 7-SIP Module, 6 Leads |
| Size / Dimension | 0.83" L x 0.83" W x 0.43" H (21.0mm x 21.0mm x 11.0mm) |
| Other | |
| Approval Agency | - |
| Dimming | - |
| Efficiency | 95% |
| Features | Remote On/Off, SCP |
| Mfr | LEDdynamics Inc. |
| Number of Outputs | 1 |
| Product Status | Obsolete |
| Series | BuckPuck™ 3021 |
| Topology | AC DC Converter |
| Type | Constant Current |
| Weight | - |
Documents
No documents are linked to this part yet.
