Phoenix ContactGermany
DC/DC CONVERTER 48V
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output (Max) | 5A |
| DC Voltage - Input (Max) | 60V |
| DC Voltage - Input (Min) | 30V |
| Power (Watts) | - |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 48V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Operating Temperature | -25°C~75°C(WithDerating) |
| Package | Bulk |
| Size / Dimension | 4.92" L x 1.89" W x 5.12" H (125.0mm x 48.0mm x 130.0mm) |
| Other | |
| Applications | ITE (Commercial) |
| Approval Agency | cUL, cULus, EAC, UL |
| Efficiency | 93% |
| Features | Adjustable Output, IP20 |
| Input Type | DC |
| Mfr | Phoenix Contact |
| Minimum Load Required | - |
| Number of Outputs | 1 |
| Product Status | Active |
| Series | Quint |
