Key specs
Coil voltage24 V
Contact formSPDT
Contact current50 mAMax
Switching voltage36 VMax
| Power | |
|---|---|
| Coil Current | 33 mA |
| Coil Voltage | 24VAC |
| Contact Rating (Current) | 50 mA |
| Must Operate Voltage | - |
| Must Release Voltage | - |
| Switching Voltage | 30VAC, 36VDC - Max |
| Environment and package | |
| Mounting Type | DIN Rail |
| Operating Temperature | -40°C ~ 50°C |
| Other | |
| Coil Insulation | - |
| Coil Type | Non Latching |
| Contact Form | SPDT (1 Form C) |
| Contact Material | Silver Nickel (AgNi), Gold (Au) |
| Features | Lighted Indicator, Socket Included, Varistor |
| Manufacturer | Phoenix Contact |
| Operate Time | 12 ms |
| Packaging | Bulk |
| Part Status | Obsolete |
| Relay Type | General Purpose |
| Release Time | 20 ms |
| Seal Rating | - |
| Series | RIF |
| Termination Style | Spring Terminal |
