Key specs
Coil voltage24 V
Contact form3PDT
Contact current10 AMax
Switching voltage440 VMax
| Power | |
|---|---|
| Coil Current | 56 mA |
| Coil Voltage | 24VDC |
| Contact Rating (Current) | 10 A |
| Must Operate Voltage | - |
| Must Release Voltage | - |
| Switching Voltage | 440VAC, 250VDC - Max |
| Environment and package | |
| Grade | - |
| Mounting Type | DIN Rail |
| Operating Temperature | -40°C ~ 60°C |
| Qualification | - |
| Other | |
| Approval Agency | CSA |
| Base Product Number | 29032 |
| Coil Insulation | - |
| Coil Resistance | 429 Ohms |
| Coil Type | Non Latching |
| Contact Form | 3PDT (3 Form C) |
| Contact Material | Silver Nickel (AgNi) |
| Features | Diode, Lighted Indicator, Socket Included |
| Load - Max Switching | 4400VA, 2500W |
| Mfr | Phoenix Contact |
| Operate Time | 20 ms |
| Packaging | Bulk |
| Part Status | Last Time Buy |
| Relay Type | General Purpose |
| Release Time | 20 ms |
| Seal Rating | - |
| Series | RIF |
| Termination Style | Screw Terminal |
