Key specs
Coil voltage24 V
Contact formSPDT
Contact current6 AMax
Switching voltage250 VMax
| Power | |
|---|---|
| Coil Current | 21 mA |
| Coil Voltage | 24VDC |
| Contact Rating (Current) | 6 A |
| Must Operate Voltage | - |
| Must Release Voltage | - |
| Switching Voltage | 250VAC, 250VDC - Max |
| Environment and package | |
| Grade | - |
| Mounting Type | Socketable |
| Operating Temperature | -20°C ~ 60°C |
| Qualification | - |
| Other | |
| Approval Agency | EAC |
| Base Product Number | 28210 |
| Coil Insulation | - |
| Coil Resistance | 114.3 Ohms |
| Coil Type | Non Latching |
| Contact Form | SPDT (1 Form C) |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Features | - |
| Load - Max Switching | - |
| Mfr | Phoenix Contact |
| Operate Time | 15 ms |
| Packaging | Bulk |
| Part Status | Obsolete |
| Relay Type | General Purpose |
| Release Time | 25 ms |
| Seal Rating | - |
| Series | ST-REL3 |
| Termination Style | Plug In |
