View full reportTechnical parameters
| Power | |
|---|---|
| Current - IEC | 32 A |
| Voltage - IEC | 800V |
| Voltage - UL | - |
| Other | |
| Color | Orange |
| Disconnect Type | - |
| Features | - |
| Fuse Type | - |
| Manufacturer | Conta-Clip, Inc. |
| Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polyamide (PA66), Nylon 6/6 |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Packaging | Box |
| Part Status | Active |
| Series | PRK |
| Stripping Length | 12mm |
| Terminal - Width | 6.1mm |
| Termination Style | Push In, Spring |
| Type | Feed Through |
| Wire Gauge or Range - AWG | 10-21 AWG |
| Wire Gauge or Range - mm² | 0.5-6mm² |
Documents
No documents are linked to this part yet.
