Pololu CorporationUnited States
HOOK-UP STRND 24AWG 300V WHT 60'
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Voltage | 300V |
| Environment and package | |
| Operating Temperature | 80°C |
| Package | Spool |
| Other | |
| Cable Type | Hook-Up |
| Conductor Material | Copper |
| Conductor Strand | 11/34 |
| Features | - |
| Jacket Color | White |
| Jacket (Insulation) Diameter | 0.055" (1.40mm) |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.015" (0.38mm) |
| Length | 60.00' (18.29m) |
| Mfr | Pololu Corporation |
| Product Status | Active |
| Ratings | UL Style 1007 |
| Series | - |
| Wire Gauge | 24 AWG |
Documents
No documents are linked to this part yet.
