FIXED IND 100UH 970MA 350MOHM SM
All alternatives
View full reportTechnical parameters
Key specs
Inductance100 µH
Rated current970 mAMax
DC resistance350 mΩMax
| Power | |
|---|---|
| Current Rating (Amps) | 970 mA |
| Current - Saturation (Isat) | - |
| AC and DC characteristics | |
| Frequency - Self Resonant | 6.56MHz |
| Inductance Frequency - Test | 1 kHz |
| Environment and package | |
| Height - Seated (Max) | 0.228" (5.80mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Package / Case | Nonstandard |
| Size / Dimension | 0.394" L x 0.354" W (10.00mm x 9.00mm) |
| Supplier Device Package | - |
| Other | |
| Base Product Number | 26 |
| DC Resistance (DCR) | 350mOhm Max |
| Inductance | 100 µH |
| Material - Core | - |
| Mfr | Murata Power Solutions Inc. |
| Product Status | Active |
| Q @ Freq | - |
| Ratings | - |
| Series | 2600 |
| Shielding | Unshielded |
| Tolerance | - |
| Type | Wirewound |
