ebm-papst Inc.Germany
FAN AXIAL 25X8MM 5VDC WIRE
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | - |
| Power (Watts) | 600 mW |
| Voltage Range | 4.5 ~ 5.5VDC |
| Voltage - Rated | 5VDC |
| AC and DC characteristics | |
| Noise | 23.0dB(A) |
| Environment and package | |
| Lifetime @ Temp. | 35000 Hrs @ 20°C |
| Operating Temperature | 14 ~ 131°F (-10 ~ 55°C) |
| Package | Box |
| Size / Dimension | Square - 25mm L x 25mm H |
| Other | |
| Air Flow | 2.6 CFM (0.073m³/min) |
| Approval Agency | CE, CSA, UL, VDE |
| Base Product Number | 255 |
| Bearing Type | Sintec |
| Fan Type | Tubeaxial |
| Features | - |
| Ingress Protection | - |
| Material - Blade | Polyamide (PA), Nylon, Fiberglass Reinforced |
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Mfr | ebm-papst Inc. |
| Product Status | Active |
| RPM | 12000 RPM |
| Series | 250 |
| Static Pressure | - |
| Termination | 2 Wire Leads |
| Weight | 0.011 lb (4.99 g) |
| Width | 8.00mm |
