252205
AmphenolUnited States

252205

Active

MCX Plug to MCX Plug Adapter 50 Ohm Straight

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

AC and DC characteristics
Impedance (Ohms)50
Environment and package
Mil QualifiedNot Mil Qualified
Panel Mounting FeatureNot Applicable
Temp (Max Degrees Celsius)165
Temp (Min Degrees Celsius)-65
Other
Adapter ConfigurationMCX Plug to MCX Plug
Adapter TypeIn-Series
AttributesAdapter Configuration
Body FinishGold
Body MaterialBeryllium Copper
California Prop 65California Residents see Prop 65 Warning
Contact FinishGold
Contact MaterialBrass
Country of OriginCN
DetailsMCX Plug to MCX Plug
Document Title252205 STP 3D Model (Size: 312.1 KB)
ECCNEAR99
HTS Code8536.69.4010
Insulator MaterialPTFE
IP RatingNot Rated
IsolatedNo
Low PIMNo
Non MagneticContains Magnetic Materials
OrientationStraight
PFASContains PFAS
Publish Date3/31/2026
StatusUnder Review
Typestp
