WeidmüllerGermany
CABLE GLAND 6-12MM M20 BRASS
All alternatives
View full reportTechnical parameters
| Environment and package | |
|---|---|
| Conduit Hub Size | - |
| Operating Temperature | - |
| Package | Bulk |
| Panel Hole Size | - |
| Thread Size | M20 |
| Other | |
| Base Product Number | VG M20 |
| Color | Silver |
| Includes | - |
| Ingress Protection | IP54/IP66/IP67/IP68/IP69K - Dust Protected, Dust Tight, Water Resistant, Waterproof |
| Material | Brass, Nickel Plated |
| Mfr | Weidmüller |
| Outside Cable Diameter (Max) | 0.472" (12.00mm) |
| Outside Cable Diameter (Min) | 0.236" (6.00mm) |
| Product Status | Active |
| Series | VG |
| Thread Length | 0.236" (6.00mm) |
| Type | Cable Gland |
Documents
No documents are linked to this part yet.
