242210
AmphenolUnited States

242210

ActiveCoaxial Connector (RF) Adapters

CONN ADAPT MCX PLUG TO TNC PLUG

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

AC and DC characteristics
Frequency - Max6 GHz
Impedance50Ohm
Environment and package
Mounting Feature-
Mounting TypeFree Hanging (In-Line)
Operating Temperature-65°C~165°C
PackageBulk
Other
Adapter SeriesMCX to TNC
Adapter TypePlug to Plug
Base Product Number2422
Body FinishNickel
Body MaterialBeryllium Copper
Center Contact MaterialBrass
Center Contact PlatingGold
Center GenderMale to Male
Conversion TypeBetween Series
Convert From (Adapter End)MCX Plug, Male Pin
Convert To (Adapter End)TNC Plug, Male Pin
Dielectric MaterialPolytetrafluoroethylene (PTFE)
Fastening TypeSnap-On, Threaded
Features-
Includes-
Ingress Protection-
Insertion Loss-
Mating Cycles-
MfrAmphenol RF
Product StatusActive
Series-
StyleStraight
