242200-10
AmphenolUnited States

242200-10

Active

SMA Plug to SSMB Jack Adapter 50 Ohm Straight

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

AC and DC characteristics
Frequency (Max GHz)4
Impedance (Ohms)50
Environment and package
Mil QualifiedNot Mil Qualified
Panel Mounting FeatureNot Applicable
Temp (Max Degrees Celsius)165
Temp (Min Degrees Celsius)-65
Other
Adapter ConfigurationSMA Plug to SSMB Jack
Adapter TypeBetween-Series
AttributesAdapter Configuration
Body FinishGold
Body MaterialBrass
Contact FinishGold
Contact MaterialBrass
Country of OriginCN
DetailsSMA Plug to SSMB Jack
Document Title242200-10 PDF Customer Drawing (Size: 48.8 KB)
ECCNEAR99
HTS Code8538.90.8180
Insulator MaterialPTFE
IP RatingNot Rated
IsolatedNo
Low PIMNo
Non MagneticContains Magnetic Materials
OrientationStraight
PFASContains PFAS
Publish Date5/7/2026
Typepdf
