View full reportTechnical parameters
| Power | |
|---|---|
| Power supply | 5 V DC 12 V DC 18...36 V DC |
| Environment and package | |
| Dimension | 45 mm x 118 mm x 137 mm |
| Working temperature | 0 °C ... 50 °C |
| Other | |
| Connection types | Screw terminals Sub-D connector |
| Input interfaces | SSI, binär SSI, gray |
| Inputs coding | D+, D-, Clk+, Clk-, GND D+, D-, Clk+, Clk-, GND |
| Output interfaces | Parallel |
| Outputs coding | Bit1...25, Vs, Strobe, Hold, GND |
| Protection level | IP20 |
| SK 1S-1P PDF ∼ 749,7 KB | 09.2025 | DE EN FR |
| SK 1S-1P PDF ∼ 938,3 KB | 09.2025 | DE EN FR |
