View full reportTechnical parameters
Key specs
Pitch5 mm
| Power | |
|---|---|
| Current | 10 A |
| Voltage | 300 V |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | - |
| Other | |
| Clamp Material - Plating | - |
| Color | - |
| Contact Material - Plating | - |
| Features | Interlocking (Side) |
| Housing Material | Polyamide (PA), Nylon |
| Manufacturer | Phoenix Contact |
| Mating Orientation | 45° (135°) Angle with Board |
| Number of Levels | 1 |
| Packaging | Bulk |
| Part Status | Active |
| Pitch | 0.197" (5.00mm) |
| Positions Per Level | 2 |
| Screw Material - Plating | - |
| Screw Thread | - |
| Series | COMBICON ZFKDSA |
| Torque - Screw | - |
| Wire Gauge | 12-26 AWG |
| Wire Termination | Screwless - Spring Cage, Tension Clamp |
Documents
No documents are linked to this part yet.
