WeidmüllerGermany
TERM BLK 8POS SIDE ENTRY 5MM PCB
All alternatives
View full reportTechnical parameters
Key specs
Pitch5 mm
| Power | |
|---|---|
| Current | 20 A |
| Voltage | 300 V |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -50°C~120°C |
| Package | Bulk |
| Other | |
| Clamp Material - Plating | - |
| Color | - |
| Contact Material - Plating | Copper Alloy - Tin Plated |
| Features | Interlocking (Side) |
| Housing Material | - |
| Mating Orientation | Horizontal with Board |
| Mfr | Weidmüller |
| Number of Levels | 1 |
| Pitch | 0.197" (5.00mm) |
| Positions Per Level | 8 |
| Product Status | Active |
| Screw Material - Plating | - |
| Screw Thread | M3 |
| Series | Omnimate LL |
| Torque - Screw | 0.5-0.6 Nm (4.4-5.3 Lb-In) |
| Wire Gauge | 12-28 AWG |
| Wire Termination | Screw - Clamping Yoke, Tension Sleeve |
