Comair RotronUnited States
FAN AXIAL 80X32MM 24VDC ST24A3
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.140A |
| Power (Watts) | 3.3 W |
| Voltage Range | 12 ~ 28VDC |
| Voltage - Rated | 24VDC |
| AC and DC characteristics | |
| Noise | 40.9dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | - |
| Size / Dimension | Square - 80mm L x 80mm H |
| Other | |
| Air Flow | 34.0 CFM (0.952m³/min) |
| Approval Agency | - |
| Bearing Type | Sleeve |
| Fan Type | Tubeaxial |
| Features | - |
| Ingress Protection | - |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Mfr | Comair Rotron |
| Product Status | Obsolete |
| RPM | 3440 RPM |
| Series | Sprint |
| Static Pressure | 0.225 in H2O (56.0 Pa) |
| Termination | 2 Wire Leads |
| Weight | 0.397 lb (180.08 g) |
| Width | 32.00mm |
Documents
No documents are linked to this part yet.
