B&K PrecisionUnited States
1-30V, 30A SWITCHING DC POWER SU
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output | 0 ~ 30A |
| Power (Watts) | - |
| Voltage - Output | 1 ~ 32VDC |
| Voltage - Supply | 120VAC |
| AC and DC characteristics | |
| Accuracy - Voltmeter; Ammeter | 0.2% + 3 counts |
| Current Regulation - Line | 50mA |
| Current Regulation - Load | 150mA |
| Ripple | 5mV rms |
| Voltage Regulation - Line | 20mV |
| Voltage Regulation - Load | 50mV |
| Environment and package | |
| Package | Box |
| Size / Dimension | 10.800" L x 7.900" W x 3.500" H (274.32mm x 200.66mm x 88.90mm) |
| Other | |
| Display Type | LED |
| Features | Adjustable or Fixed Selection Switch |
| Mfr | B&K Precision |
| Number of Characters | 3 (2) |
| Number of Outputs | 1 |
| Product Status | Active |
| Series | 1900B |
| Type | Bench (AC to DC) |
| Weight | 7 lbs (3.2 kg) |
