Key specs
Pitch3.5 mm
| Power | |
|---|---|
| Current | 10 A |
| Voltage | 300 V |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | - |
| Other | |
| Clamp Material - Plating | - |
| Color | Black |
| Contact Material - Plating | Tin Plated |
| Features | Board Guide |
| Housing Material | Liquid Crystal Polymer (LCP) |
| Manufacturer | Phoenix Contact |
| Mating Orientation | Horizontal with Board |
| Number of Levels | 1 |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status | Active |
| Pitch | 0.138" (3.50mm) |
| Positions Per Level | 10 |
| Screw Material - Plating | - |
| Screw Thread | - |
| Series | COMBICON SPT-SMD |
| Torque - Screw | - |
| Wire Gauge | 16-24 AWG |
| Wire Termination | Screwless - Leg Spring, Push-In Spring |
