View full reportTechnical parameters
| Power | |
|---|---|
| LED power | 20mA |
| LED voltage | 2,1V |
| Environment and package | |
| Ambienttemperature | -40°C ... +85°C |
| Height (mm) | 10,1 |
| LED-dimensions | 5 |
| Mounting | THT |
| Other | |
| Bez 1 | Single LED-display |
| Bez 2 | THT hor. 5mm yellow 2,1V |
| Bez 3 | 20mA 30mcd long contacts |
| bildthumbnail | 1800.2032.jpg |
| Colour | black |
| Connections | wire |
| Design | long contacts |
| Inner diameter (mm) | 5 |
| LED | A7 |
| LED beam angle | 60° |
| LED-colour | yellow |
| ledhelligkeit | 30mcd |
| LED-shape | rectangular |
| ledtype | a |
| LED wavelength | 588nm |
| Length (mm) | 24,66 |
| Material | plastic |
| Material 1 | PC |
| MOQ 2 | on request |
| Orientation | hor. |
| Partnumber | 1800.7031 |
| rank_math_internal_links_processed | 1 |
| Stock | yes |
| Type | Single LED-display |
| Width (mm) | 10,1 |
