WeidmüllerGermany
TERM BLK 3POS SIDE ENTRY 5MM PCB
All alternatives
View full reportTechnical parameters
Key specs
Pitch5 mm
| Power | |
|---|---|
| Current | 15 A |
| Voltage | 300 V |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -50°C~120°C |
| Package | Bulk |
| Other | |
| Clamp Material - Plating | - |
| Color | Orange |
| Contact Material - Plating | Copper Alloy - Tin Plated |
| Features | Interlocking (Side) |
| Housing Material | Thermoplastic, Wemid |
| Mating Orientation | Horizontal with Board |
| Mfr | Weidmüller |
| Number of Levels | 1 |
| Pitch | 0.197" (5.00mm) |
| Positions Per Level | 3 |
| Product Status | Active |
| Screw Material - Plating | - |
| Screw Thread | M2.5 |
| Series | Omnimate PM |
| Torque - Screw | 0.4-0.5 Nm (3.5-4.4 Lb-In) |
| Wire Gauge | 14-26 AWG |
| Wire Termination | Screw - Leaf Spring, Wire Guard |
