172228-14
AmphenolUnited States

172228-14

ActiveCoaxial Connector (RF) Assemblies

CONN N RCPT STR 50 OHM SOLDER

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Connector styleType N
GenderFemale
Impedance50 Ω
Max frequency11 GHzMax
Power
Voltage Rating1500 V
AC and DC characteristics
Frequency - Max11 GHz
Impedance50Ohm
Environment and package
Mounting FeatureFlange
Mounting TypePanel Mount
Operating Temperature-65°C~165°C
PackageBulk
Other
Base Product Number172228
Body FinishWhite Bronze
Body MaterialBrass
Cable Group-
Center Contact MaterialBeryllium Copper
Center Contact PlatingGold
Connector StyleN Type
Connector TypeReceptacle, Female Socket
Contact TerminationSolder
Dielectric MaterialPolytetrafluoroethylene (PTFE)
Fastening TypeThreaded
FeaturesExtended Insulation
Housing ColorSilver
Includes-
Ingress Protection-
Insertion Loss0.15dB
Mating Cycles500
MfrAmphenol RF
Number of Ports1
Product StatusActive
Series-
Shield TerminationSolder
