AmphenolUnited States
CONN N JACK STR 50 OHM SOLDER
All alternatives
View full reportTechnical parameters
Key specs
Connector styleType N
GenderFemale
Impedance50 Ω
Max frequency11 GHzMax
| Power | |
|---|---|
| Voltage Rating | 1500 V |
| AC and DC characteristics | |
| Frequency - Max | 11 GHz |
| Impedance | 50 Ohms |
| Environment and package | |
| Mounting Feature | Flange |
| Mounting Type | Panel Mount |
| Operating Temperature | -65°C ~ 165°C |
| Other | |
| Base Product Number | 1721 |
| Body Finish | White Bronze |
| Body Material | Brass |
| Cable Group | RG-405 (.085", .086" Semi Rigid) |
| Center Contact Material | Phosphor Bronze |
| Center Contact Plating | Gold |
| Connector Style | N Type |
| Connector Type | Jack, Female Socket |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Fastening Type | Threaded |
| Features | - |
| Housing Color | Silver |
| Includes | 4 pcs - 1 Connector, 1 Contact, 1 Insulator, 1 Nut |
| Ingress Protection | - |
| Insertion Loss | 0.15dB |
| Mating Cycles | 500 |
| Mfr | Amphenol RF |
| Number of Ports | 1 |
| Packaging | Bag |
| Part Status | Active |
| Series | - |
| Shield Termination | Solder |
