172168
AmphenolUnited States

172168

ActiveCoaxial Connector (RF) Assemblies

N TYPE STRAIGHT CRIMP JACK FOR R

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Connector styleType N
GenderFemale
Impedance50 Ω
Max frequency11 GHzMax
AC and DC characteristics
Frequency - Max11 GHz
Impedance50Ohm
Environment and package
Mounting FeatureBulkhead - Front Side Nut
Mounting TypePanel Mount
Operating Temperature-65°C~165°C
PackageBag
Other
Base Product Number1721
Body FinishWhite Bronze
Body MaterialBrass
Cable GroupRG-8, 8A, 9, 9A, 9B, 87, 213, 214, 225, 302, 393
Center Contact MaterialBeryllium Copper
Center Contact PlatingGold
Connector StyleN Type
Connector TypeJack, Female Socket
Contact TerminationCrimp
Dielectric MaterialPolytetrafluoroethylene (PTFE)
Fastening TypeThreaded
Features-
Housing ColorSilver
Includes-
Ingress Protection-
Insertion Loss-
Mating Cycles500
MfrAmphenol RF
Number of Ports1
Product StatusActive
Series-
Shield TerminationCrimp
