View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Impedance (Ohms) | 50 |
| Environment and package | |
| Mil Qualified | Not Mil Qualified |
| Panel Mounting Feature | Not Applicable |
| Size Category | Standard |
| Temp (Max Degrees Celsius) | 165 |
| Temp (Min Degrees Celsius) | -65 |
| Other | |
| Attributes | Body Finish |
| Body Finish | Nickel |
| Body Material | Brass |
| Cable Type (Terminates To) | RG-8, RG-213, RG-225, Times AA-4478, Belden 8267, Belden 9251, Belden 9880, Belden 89880, Belden 8242, Belden 8268 |
| California Prop 65 | California Residents see Prop 65 Warning |
| Contact Finish | Gold |
| Contact Termination | Solder |
| Country of Origin | CN |
| Coupling Mechanism | Threaded |
| Details | Nickel |
| Document Title | Status |
| ECCN | EAR99 |
| Gender | Plug |
| HTS Code | 8536.69.4010 |
| Insulator Material | PTFE |
| IP Rating | Not Rated |
| Isolated | No |
| Low PIM | No |
| Mating Cycles (Min) | 500 |
| Non Magnetic | Contains Magnetic Materials |
| Orientation | Straight |
| PFAS | Contains PFAS |
| Ports | 1 (Single Port) |
| Status | Under Review |
| Termination Style | Cable - Crimp |
| Thread Direction | Standard |
