172127S
AmphenolUnited States

172127S

Active

N-Type T-Shape Adapter Jack-Jack-Jack 50 Ohm

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

AC and DC characteristics
Frequency (Max GHz)11
Impedance (Ohms)50
Environment and package
Mil QualifiedNot Mil Qualified
Panel Mounting FeatureNot Applicable
Temp (Max Degrees Celsius)165
Temp (Min Degrees Celsius)-65
Other
Adapter TypeIn-Series
AttributesAdapter Type
Body FinishSilver
Body MaterialBrass
Contact FinishGold
Contact MaterialBrass
Country of OriginCN
DetailsIn-Series
ECCNEAR99
HTS Code8536.69.4010
Insulator MaterialPTFE
IP RatingNot Rated
IsolatedNo
Low PIMNo
Non MagneticContains Magnetic Materials
PFASContains PFAS
Tee Adapter GenderJack-Jack-Jack
Unit Weight (Grams)68.666
