View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Frequency (Max GHz) | 11 |
| Impedance (Ohms) | 50 |
| Environment and package | |
| Mil Qualified | Not Mil Qualified |
| Panel Mounting Feature | Bulkhead |
| Temp (Max Degrees Celsius) | 85 |
| Temp (Min Degrees Celsius) | -40 |
| Other | |
| Adapter Configuration | N-Type Jack to N-Type Jack |
| Adapter Type | In-Series |
| Attributes | Adapter Configuration |
| Body Finish | Silver |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Phosphor Bronze |
| Country of Origin | CN |
| Details | N-Type Jack to N-Type Jack |
| Document Title | 172124-10S PDF Customer Drawing (Size: 41.3 KB) |
| ECCN | EAR99 |
| HTS Code | 8538.90.8180 |
| Insulator Material | PTFE |
| IP Rating | Not Rated |
| Isolated | No |
| Low PIM | No |
| Non Magnetic | Contains Magnetic Materials |
| Orientation | Straight |
| PFAS | Contains PFAS |
| Publish Date | 5/7/2026 |
| Type | |
