172120RP
AmphenolUnited States

172120RP

Active

RP-N-Type Panel Mount Plug 4-Hole Flange Slot 50 Ohm

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

AC and DC characteristics
Impedance (Ohms)50
Environment and package
Mil QualifiedNot Mil Qualified
Panel Mounting Feature4-Hole Flange
Size CategoryStandard
Temp (Max Degrees Celsius)165
Temp (Min Degrees Celsius)-65
Other
AttributesBody Finish
Body FinishNickel
Body MaterialBrass
Contact FinishGold
Contact MaterialBeryllium Copper
Contact TerminationSolder
Country of OriginCN
Coupling MechanismThreaded
DetailsNickel
ECCNEAR99
GenderPlug
HTS Code8536.69.4010
Insulator MaterialPTFE
IP RatingNot Rated
IsolatedNo
Low PIMNo
Mating Cycles (Min)500
Non MagneticContains Magnetic Materials
OrientationStraight
PFASContains PFAS
Ports1 (Single Port)
Termination StyleSlot
Thread DirectionStandard
