方向电子China
16008-60JXX1_BTB F-SV-1-2x9-P050-H15
All alternatives
View full reportTechnical parameters
Key specs
GenderFemale
| Environment and package | |
|---|---|
| Height(mm) | 1.45 |
| Operating Temperature | -40~85℃ |
| UL/RoHS Compliance | Yes |
| Other | |
| Coplanarity | 0.1mm Max |
| Gender | Receptacle |
| Length(mm) | 7.1 |
| Number of Contact | 18 |
| Number of Row | Double Row |
| Pin Pitch(mm) | 0.5 |
| Width(mm) | 6 |
