View full reportTechnical parameters
| Power | |
|---|---|
| Power (VA) | 500 |
| Voltage - Primary (V) | 230 |
| Voltage - Secondary (V) | 115 |
| AC and DC characteristics | |
| Frequency (Hz) | 50/60 |
| Environment and package | |
| Height in (mm) | 3.87 (98.3) |
| Mounting Type | Chassis Mount |
| RoHS Compliant | Yes |
| Other | |
| Brand | Signal Transformer |
| Insulation Class | Class B, 130ºC |
| Length in (mm) | 3.25 (82.6) |
| Weight lbs (kg) | 8 (3.63) |
| Width in (mm) | 4.87 (123.7) |
