View full reportTechnical parameters
| Power | |
|---|---|
| Standard dielectric voltage | IEC664-1 |
| Standard working voltage | DIN41652 |
| Environment and package | |
| max. working temperature | +105° C |
| min. working temperature | -15° C |
| Other | |
| Contact resistance standard | 10 mOhm |
| Extraction force | 30 N |
| Hardware options mating side | Threaded bolt |
| Insertion force | 30 N |
| Insulator color | Black |
| Insulator material | PBT GF UL 94 V-0 |
| IP rating | IP67 in connected condition |
| Length cable/wire | 4 m |
| Mating cycles | 50 |
| Plating signal contact (mating area) | Gold over nickel |
| Quality class | Quality class 3 |
| Signal contact material | Copper alloy |
| Standard insertion / extraction force | DIN41652 |
| Standard IP rating | IEC 60529 |
| Standard mating cycles | DIN41652 |
| Termination signal [e.g. clamp, crimp, solder, SMT] | With Cable |
| Thread type | for cable assembly with open 4-40 UNC thread |
