View full reportTechnical parameters
| Power | |
|---|---|
| Current rating power | 20 A |
| Dielectric with standing voltage power | 1000 V |
| Material power contact | Copper alloy |
| Plating power contact (mating area) | Gold over nickel |
| Plating power contact (termination area) | Gold over nickel |
| Power resistance standard | 1 mOhm |
| Standard dielectric voltage | IEC664-1 |
| Standard working voltage | DIN41652 |
| Termination power contact | Solder cup |
| Working voltage power | 250 V |
| Environment and package | |
| max. working temperature | +105° C |
| min. working temperature | -40° C |
| Mounting option material | Stainless Steel |
| Mounting style | Straight |
| Other | |
| Hardware options mating side | Threaded insert |
| Hardware options termination side | Threaded Insert |
| Insulator color | Green |
| Insulator material | PBT GF UL 94 V-0 |
| IP rating | IP67 in connected condition |
| Mating cycles | 50 |
| Plating signal contact (mating area) | Gold over nickel |
| Plating signal contact (termination area) | Gold over nickel |
| Quality class | Quality class 3 |
| Shell material | Zinc die cast |
| Shell plating | Nickel |
| Signal contact material | Copper alloy |
| Standard mating cycles | DIN41652 |
| Thread type | for cable assembly with open 4-40 UNC thread |
