Key specs
GenderMale
Impedance50 Ω
Max frequency300 MHzMax
| Power | |
|---|---|
| Voltage Rating | 500 V |
| AC and DC characteristics | |
| Frequency - Max | 0.3 GHz |
| Impedance | 50 Ohms |
| Environment and package | |
| Mounting Feature | - |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | -65°C ~ 165°C |
| Other | |
| Body Finish | Nickel |
| Body Material | Brass |
| Cable Group | RG-8, 8A, 9, 9A, 9B, 87, 213, 214, 225, 302, 393 |
| Center Contact Material | Silver |
| Center Contact Plating | Silver |
| Connector Style | UHF |
| Connector Type | Plug, Male Pin |
| Contact Termination | Crimp |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Fastening Type | Threaded |
| Housing Color | Silver |
| Includes | - |
| Ingress Protection | - |
| Mating Cycles | 500 |
| Mfr | Ease Electronics |
| Number of Ports | 1 |
| Packaging | Bag |
| Part Status | Active |
| Series | COAX-CN-RS |
| Shield Termination | Crimp |
