WeidmüllerGermany
IE-PCB-RJ45-THR-C6-180
All alternatives
View full reportTechnical parameters
Key specs
Rows1
GenderFemale
| Environment and package | |
|---|---|
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~85°C |
| Package | Tray |
| Other | |
| Connector Type | Jack |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Material | Phosphor Bronze |
| Features | - |
| Housing Material | Polyamide (PA66), Nylon 6/6 |
| Ingress Protection | IP20 |
| LED Color | Does Not Contain LED |
| Mfr | Weidmüller |
| Number of Ports | 1 |
| Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
| Number of Rows | 1 |
| Orientation | Vertical |
| Product Status | Obsolete |
| Ratings | Cat6 |
| Series | - |
| Shielding | Shielded |
| Tab Direction | User Selectable |
| Termination | Solder |
Documents
No documents are linked to this part yet.
