View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Frequency (Max GHz) | 4 |
| Impedance (Ohms) | 50 |
| Environment and package | |
| Mil Qualified | Not Mil Qualified |
| Panel Mounting Feature | Not Applicable |
| Size Category | Subminiature |
| Temp (Max Degrees Celsius) | 165 |
| Temp (Min Degrees Celsius) | -65 |
| Other | |
| Attributes | Body Finish |
| Body Finish | Nickel |
| Body Material | Brass |
| Cable Type (Terminates To) | 1.37 mm Micro-cable |
| Contact Finish | Gold |
| Contact Material | Beryllium Copper |
| Contact Termination | Solder |
| Country of Origin | CN |
| Coupling Mechanism | Push-on |
| Details | Nickel |
| Document Title | Assembly Instructions C61 (Size: 33.8 KB) |
| ECCN | EAR99 |
| Gender | Plug |
| HTS Code | 8536.69.4010 |
| Insulator Material | PTFE |
| IP Rating | Not Rated |
| Isolated | No |
| Low PIM | No |
| Mating Cycles (Min) | 500 |
| Non Magnetic | Contains Magnetic Materials |
| Orientation | Right Angle |
| PFAS | Contains PFAS |
| Ports | 1 (Single Port) |
| Publish Date | 4/20/2026 |
| Termination Style | Cable - Crimp |
| Thread Direction | Standard |
| Type | |
