View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Frequency - Max | 6 GHz |
| Overall Impedance | 50 Ohms |
| Environment and package | |
| 1st Connector Mounting Feature | - |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 2nd Connector Mounting Feature | - |
| 2nd Connector Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | -40°C~85°C |
| Package | Bulk |
| Other | |
| 1st Connector | RP-SMA Plug |
| 1st Contact Gender | Female |
| 2nd Connector | N-Type Plug |
| 2nd Contact Gender | Male |
| Cable Type | Low Smoke Zero Halogen (LSZH) |
| Color | Black |
| Features | - |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Length | 157.5" (4.0m) 13.1' |
| Mfr | Weidmüller |
| Product Status | Active |
| Series | - |
| Style | RP-SMA to N-Type |
Documents
No documents are linked to this part yet.
