WeidmüllerGermany
TERM BLOCK PLUG 7POS STR 5.08MM
All alternatives
View full reportTechnical parameters
Key specs
Positions7
Pitch5.08 mm
| Power | |
|---|---|
| Current - IEC | 17.5A |
| Current - UL | 10 A |
| Voltage - IEC | 400 V |
| Voltage - UL | 300 V |
| Environment and package | |
| Insulation Height | 0.598" (15.19mm) |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature | -50°C~120°C |
| Package | Bulk |
| Screw Size | M2.5 |
| Other | |
| Color | Orange |
| Contact Material | Copper Alloy |
| Contact Mating Finish | Tin |
| Contact Tail Length | - |
| Features | - |
| Header Orientation | - |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Mfr | Weidmüller |
| Number of Levels | 1 |
| Number of Positions | 7 |
| Pitch | 0.200" (5.08mm) |
| Plug Wire Entry | 180° |
| Positions Per Level | 7 |
| Product Status | Active |
| Series | Unimate BLA |
| Termination Style | Screw - Clamping Yoke (Tension Sleeve) |
| Torque - Screw | 0.4-0.5 Nm (3.5-4.4 Lb-In) |
| Type | Plug, Female Sockets |
| Wire Gauge or Range - AWG | 12-26 AWG |
| Wire Gauge or Range - mm² | 0.2-2.5mm² |
| Wire Strip Length | 7mm |
