132422-10
AmphenolUnited States

132422-10

ActiveCoaxial Connector (RF) Assemblies

SMA CRIMP JACK FOR 1.13MM, IP-67

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Connector styleSMA
GenderFemale
Impedance50 Ω
Max frequency6 GHzMax
AC and DC characteristics
Frequency - Max6 GHz
Impedance50Ohm
Environment and package
Mounting FeatureBulkhead - Front Side Nut
Mounting TypePanel Mount
Operating Temperature-65°C~165°C
PackageBag
Other
Base Product Number132422
Body FinishGold
Body MaterialBrass
Cable Group1.13mm Coaxial Cable
Center Contact MaterialBeryllium Copper, Brass
Center Contact PlatingGold
Connector StyleSMA
Connector TypeJack, Female Socket
Contact TerminationSolder
Dielectric MaterialPolytetrafluoroethylene (PTFE)
Fastening TypeThreaded
Features-
Housing ColorGold
Includes-
Ingress ProtectionIP67 - Dust Tight, Waterproof
Insertion Loss-
Mating Cycles500
MfrAmphenol RF
Number of Ports1
Product StatusActive
Series-
Shield TerminationCrimp
