132131
AmphenolUnited States

132131

ActiveCoaxial Connector (RF) Assemblies

CONN SMA PLUG R/A 50OHM SOLDER

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Connector styleSMA
GenderMale
Impedance50 Ω
Max frequency12.4 GHzMax
Power
Voltage Rating375 V
AC and DC characteristics
Frequency - Max12.4 GHz
Impedance50Ohm
Environment and package
Mounting Feature-
Mounting TypeFree Hanging (In-Line), Right Angle
Operating Temperature-65°C~165°C
PackageBulk
Other
Base Product Number1321
Body FinishGold
Body MaterialBrass
Cable GroupRG-174, 188, 188A, 316, LMR-100, M17/119-RG174
Center Contact MaterialBrass
Center Contact PlatingGold
Connector StyleSMA
Connector TypePlug, Male Pin
Contact TerminationSolder
Dielectric MaterialPolytetrafluoroethylene (PTFE)
Fastening TypeThreaded
Features-
Housing ColorGold
Includes-
Ingress Protection-
Insertion Loss-
Mating Cycles500
MfrAmphenol RF
Number of Ports1
Product StatusActive
Series-
Shield TerminationClamp
