132118RT
AmphenolUnited States

132118RT

Active

SMA Straight Crimp Jack RG-58 RG-141 Times LMR-195 Bulkhead 50 Ohm

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

AC and DC characteristics
Impedance (Ohms)50
Environment and package
Mil QualifiedNot Mil Qualified
Panel Mounting FeatureBulkhead - Rear Mount
Size CategorySubminiature
Temp (Min Degrees Celsius)-65
Other
AttributesBody Finish
Body FinishGold
Body MaterialBrass
Cable Type (Terminates To)RG-58, RG-141, Times LMR-195, Times LMR-200-LLPL, Belden 7806A, Belden 8219, Belden 8240, Belden 8259, Belden 8262, Belden 9201, Belden 9203, Belden 9310, Belden 9311
California Prop 65California Residents see Prop 65 Warning
Contact FinishGold
Contact MaterialBeryllium Copper
Contact TerminationSolder
Country of OriginCN
Coupling MechanismThreaded
DetailsGold
Document TitleAssembly Instructions 3 Piece Crimp-Solder (Size: 44.1 KB)
ECCNEAR99
GenderJack
HTS Code8536.69.4010
Insulator MaterialPTFE
IP RatingNot Rated
IsolatedNo
Low PIMNo
Mating Cycles (Min)500
Non MagneticContains Magnetic Materials
OrientationStraight
PFASContains PFAS
Ports1 (Single Port)
Publish Date3/31/2026
StatusUnder Review
Termination StyleCable - Crimp
Thread DirectionStandard
Typepdf
