Honeywell Sensing and Productivity SolutionsUnited States
SWITCH TOGGLE DPDT 20A 125V
All alternatives
View full reportTechnical parameters
Key specs
CircuitDPDT
Switch functionOn-Off-On
Current rating20 AMax
Voltage rating125 VMax
| Power | |
|---|---|
| Current Rating (Amps) | 20A (AC) |
| Illumination Voltage (Nominal) | - |
| Voltage Rating - AC | 125 V |
| Environment and package | |
| Mounting Type | Panel Mount |
| Operating Temperature | -54°C~71°C |
| Package | Bulk |
| Panel Cutout Dimensions | Circular - 12.40mm Dia |
| Other | |
| Actuator Length | 16.51mm |
| Actuator Material | Nickel Plated |
| Actuator Type | Standard Round |
| Base Product Number | 12TS15 |
| Bushing Thread | 15/32-32 |
| Circuit | DPDT |
| Electrical Life | - |
| Features | - |
| Illumination | Non-Illuminated |
| Illumination Type, Color | - |
| Ingress Protection | - |
| Mfr | Honeywell Sensing and Productivity Solutions |
| Product Status | Obsolete |
| Series | TS |
| Switch Function | On-Off-On |
| Termination Style | Screw Terminal |
