View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Impedance (Ohms) | 75 |
| Environment and package | |
| Mil Qualified | Not Mil Qualified |
| Panel Mounting Feature | Bulkhead - Rear Mount |
| Size Category | Miniature |
| Temp (Max Degrees Celsius) | 165 |
| Temp (Min Degrees Celsius) | -65 |
| Other | |
| Attributes | Body Material |
| Body Material | Brass |
| Cable Type (Terminates To) | RG-59, RG-62, Belden 8221, Belden 8241, Belden 9169, Belden 9204, Belden 9228, Canare LV-61S |
| California Prop 65 | California Residents see Prop 65 Warning |
| Contact Finish | Gold |
| Country of Origin | CN |
| Coupling Mechanism | Threaded |
| Details | Brass |
| Document Title | Status |
| ECCN | EAR99 |
| Gender | Jack |
| HTS Code | 8536.69.4010 |
| Insulator Material | PTFE |
| IP Rating | Not Rated |
| Isolated | No |
| Low PIM | No |
| Mating Cycles (Min) | 500 |
| Non Magnetic | Contains Magnetic Materials |
| PFAS | Contains PFAS |
| Ports | 1 (Single Port) |
| Status | Under Review |
| Termination Style | Cable - Crimp |
