View full reportTechnical parameters
| Power | |
|---|---|
| Nominal current | ≤ 1 A |
| Nominal voltage | ≤ 60 V AC/DC |
| Testvoltage | 1000 V/ 50 Hz |
| Environment and package | |
| Ambienttemperature | -40°C ... +85°C |
| Height (mm) | 5,08 |
| Mounting | SMD |
| Other | |
| Bez 1 | Test jack |
| Bez 2 | SMD 2 x d=2 hor. L=17,2 ≤ |
| Bez 3 | 60 V AC/DC ≤ 1 A |
| bildthumbnail | 1212_2241.jpg |
| Clima | GPF DIN 40040 |
| Colour | grey |
| Contact resistance | < 30 mΩ |
| Feature | FEL/SMD/Rf |
| Inner diameter (mm) | 2 |
| Insulation class | VDE 0110 Group C |
| Length (mm) | 17,2 |
| Material | plastic |
| Material 1 | thermoplastic fibreglass-reinforced |
| MOQ 1 | 300 |
| MOQ 2 | on request |
| Orientation | hor. |
| Partnumber | 1212.2241 |
| Pole number | 2 |
| rank_math_internal_links_processed | 1 |
| Stock | yes |
| Type | Test jack |
| Width (mm) | 10,16 |
