| AC and DC characteristics | |
|---|---|
| Impedance (Ohms) | 75 |
| Environment and package | |
| Mil Qualified | Not Mil Qualified |
| Panel Mounting Feature | Bulkhead - Rear Mount |
| Size Category | Miniature |
| Other | |
| Attributes | Body Material |
| Body Material | Brass |
| Contact Finish | Gold |
| Country of Origin | CN |
| Coupling Mechanism | Bayonet |
| Details | Brass |
| ECCN | EAR99 |
| Gender | Jack |
| HTS Code | 8536.69.4010 |
| IP Rating | Not Rated |
| Isolated | No |
| Low PIM | No |
| Mating Cycles (Min) | 500 |
| Non Magnetic | Contains Magnetic Materials |
| Orientation | Right Angle |
| PFAS | PFAS Status Undetermined |
| Ports | 1 (Single Port) |
| Termination Style | PCB - Through Hole |
