112488
AmphenolUnited States

112488

ActiveCoaxial Connector (RF) Assemblies

CONN BNC JACK STR 50 OHM PCB

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Connector styleBNC
GenderFemale
Impedance50 Ω
Max frequency4 GHzMax
Power
Voltage Rating500 V
AC and DC characteristics
Frequency - Max4 GHz
Impedance50Ohm
Environment and package
Mounting FeatureBulkhead
Mounting TypePanel Mount, Through Hole
Operating Temperature-
PackageBag
Other
Base Product Number1124
Body FinishNickel
Body MaterialZinc Die Cast
Cable Group-
Center Contact MaterialPhosphor Bronze
Center Contact PlatingGold
Connector StyleBNC
Connector TypeJack, Female Socket
Contact TerminationSolder
Dielectric MaterialPolypropylene (PP)
Fastening TypeBayonet Lock
FeaturesBoard Lock
Housing ColorSilver
Includes-
Ingress Protection-
Insertion Loss0.2dB
Mating Cycles500
MfrAmphenol RF
Number of Ports1
Product StatusActive
Series-
Shield TerminationSolder
